Product description
Parameters
Frequency range UHF 740-790MHz
Preset channel 200 selectable (50 CHs in each channel)
Oscillation mode PLL (Phase locked loop)
Stability ± 10ppm
Frequency Response -95 ~-71dBm
Distortion ≤ 0.5%
Frequency response 40 ~ 18000 Hz
Distortion ≤ 0.5%
S/N ratio ≥ 110dB
audio output 800mv
Power supply DC12V
Power consumption ≤14W
Output 4 balaned output, 1 unbalance output
Transmitter
Frequency range 740-790MHz
Preset channel 200 selectable (50 CHs in each channel)
Oscillation mode PLL (Phase locked loop)
RF power 10 ~ 30mW
Distortion ≤ 0.5%
Battery 2*AA
Working time Over 8 hour
Features
1. UHF 4 channel wireless microphone system
2. EIA standard 1U rack mountable receiver chasis
3. Rugged metal transmitter houing
4. PLL with high-precision quartz crystal, coupled with MCU control delivers high stability.
5. IR auto scan & ACT channel sync setup
6. Comes with 4 balanced output & 1 unbalance output
7. Advance digital pilot enjoys anti-interference and superior reception.
8. High sensitivity and superior sound quality
9. SMT technics delivers high performance.
1. UHF 4 channel wireless microphone system
2. EIA standard 1U rack mountable receiver chasis
3. Rugged metal transmitter houing
4. PLL with high-precision quartz crystal, coupled with MCU control delivers high stability.
5. IR auto scan & ACT channel sync setup
6. Comes with 4 balanced output & 1 unbalance output
7. Advance digital pilot enjoys anti-interference and superior reception.
8. High sensitivity and superior sound quality
9. SMT technics delivers high performance.
